Digital Embossing Machine A1 size 600x900mm UV Flat Printer
Part I. Summary.
Ultraviolet LED Inkjet Printer (UV Flat Printer) is a high-tech, free-form full-color digital press that is not limited by materials and can be used in T-shirts, sliding doors, cabinet doors, sliding doors, glass, plates, various signs, crystals. , PVC, acrylic, metal, plastic, stone, leather and other surfaces for color photo-level printing.
No need for plate making and printing at one time, the color is bright and rich, wear-resistant, anti-ultraviolet, easy to operate, fast printing image, fully in line with industrial printing standards.
Part II. Feature.
Part III. Specification.
| Name | A1 Size 600*900mm Flatbed UV Printer |
| Model No. | BT-UV6090 |
| Printing Area | 600x900mm |
| Max. Thickness Of Flat Printing Material | 0-100mm |
| Print Heads |
2PCS Epson TX800 Print head |
| Max. Resolution |
2880*1440dpi |
| Ink Type |
UV LED couring ink |
| Color Number |
5colors / 7 colors (CMYK W LC LM) at one pass |
| Printing Interface |
USB 2.0 high speed interface & 100 Base-T Ethernet interface |
| Printing Direction | Smart Bi-directional Printing Mode |
| Printing Method | Drop on Demand (non-contact micro piezoelectric ink-jet printing technology) |
| Applicable Industry | Rigid PVC board, glass, plastic, organic board, leather, rubber, special paper, metal, wood, porcelain, PVC, ABS, acrylic, aluminum, iron sheet, ceramic tile, marble, granite, paperboard. |
| Rreprocessing of the printing material |
Specialized coating (no-coating ink can be used directly) |
| Printing method | Drop on Demand (non-contact micro piezoelectric ink-jet printing technology; micro piezoelectric printing technology; VSDT; intelligent nozzle clogging sensor system). |
| Vacuum suction platform | Equipped |
| Printing speed for A1 size |
about 3.4min(360*360dpi; draft model); about 6.9min (720*360dpi; quality model); about 14min (720*720dpi; photo quality model); 90s for A4 profile photo chrome model |
| Height detection of printing material |
Infrared sensor |
| Power consumption | 136 W/ Hour |
| Ink consumption | 10 ML/SQM |
| Ink capacity | 250ml,automatic ink volume monitoring, add ink no need to stop machine |
| Lamp type | LED Lamp (saving energy and environmental friendly) |
| Auto adjustment function | Nozzle automatic detection; print head automatic |
| Height adjustment | Auto |
| Normal workinenvironment | Temperature: 10-35Celsius; Humidity: 20-80RH |
| Power/ Voltage | 78W / 220V/110V |
| Operation system | Windows 7 32/64bit RAM≥8G |
| Support Image format | FIFF,JPEG,EPS,PD |
| Machine configuration | USB line; driving software; power line; instruction book; washing and ink-joiner tools |
| Special remark | Customized service is available. |
| Machine size/Net weight | 1578*1461*1225mm/280kgs |
| Packing size/Gross weight |
1670*1560*1380mm/350kgs |
Part IV. Application.
Part V. After-sale Service And Solution.1.One year warranty
1. You can discuss operation and maintenance with our technician online support service by Skype, WeChat, WhatsApp etc. Remote control will be provided upon request.
2. Free exchange of new components
Our quality is guaranteed 100%, the spare parts can be replaced within one year free of charge includes the airfreight by
express, except for the print head and some consumable parts.
3. Convenient online consultation
The technician will keep online. No matter what kind of technical questions that you may have, you would get a satisfying
answer from our professional technician easily. 4. Free onsite installation and training
If you are able to help us with getting the visa and also would like to bear the costs involved like flight tickets, food, etc, we
can send our technician to your office, and to give you a free installation and training for as long as you know how to operate
it.
If you are interested in this machine, please do not hesitate to contact us.
