Factory made hot-sale Sign Making Machine - BT-4040LS High Precision 3D Laser CNC Scanner – YUANNUO MACHINERY

Laser Type:

YAG

CNC or Not:

Yes

Applicable Material:

Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood

Place of Origin:

Shandong, China (Mainland)

Brand Name:

BEST

Model Number:

BT-4040LS

Certification:

CE, ISO

After-sales Service Provided:

Overseas service center available

Name:

CNC Scanner

Model No.:

BT-4040LS

Application:

Scan Relief Crafts For CNC Router, Other

Scanning Precision:

0.02mm

Scanning Area Per Time:

Width-40mm, Depth-40mm

Max. Scanning Area:

Depth-120mm

Max. Scanning Speed:

>12,000,000 dots/hour

Format Output:

bmp, bitmap, ASC, IGES, DXF, STL

Weigth:

3kg

Certificate:

ISO9001:2008

Packaging & Delivery

Packaging Details

Free-fumigation Wooden Case

Delivery Time

7 days after receiving payment

CNC Scanner
Name:
BT-4040LS High Precision 3D Laser CNC Scanner
Working Principle:
3D Laser Scanner is based on the optical triangulation principle. Use double -CCD camera to capture the scanning belt on the surface of object provided by the laser knife, and send the datas into PC to process. Via it, we can get the accurate 3D coordinate of the object, and convert them into digits. The serials of machines are used abroad in the lines of digital design and manufacturing.
3D Laser Scanner Application:
3D Laser scanner can scan and measure the objects as well as moulds rapidly, such as wooden moulds, mud moulds, wax moulds, plaster cast, silicone mold etc.
The laser line scan system have a wide range of applications in the digital design and manufacture.
It can establish CAD moulds of the 3D objects.
It’s applied abroad in areas of Auto, Motorcycle, Home Appliance, Sporting Equipments, Joy, Furniture, Anthropometry, Costumes and shoes & hats design, Cultural Relics and Antique, image and figure of body, ceramic, crafts, 3D cartoon, games, dummy environment, Reparative Medicine, medicolegal expertise, e-business etc.
3D Laser Scanner Feature:
1.Non-touch measurement.
2.High speed and high automatic.
3.Double -CCD measurement can reduce the blind spots of measuring
4.The point cloud can compose the gray scale for carving automatically
5.It can output the files in formats of  ASC, IGES, DXF, STL etc.
Integration of 3D Laser Scanner and CNC Router:
We can install the 3D Laser Scanner to CNC Router, realize integration of them, so to save cost of hardware platform. It is applied abroad in the profession of wood carving, stone carving, jade carving and other industries.
We can provide different standards of laser scanning which users needs probely.
The depth of measure 60-220mm, measurement accuracy ± 0.02-0.1mm, the speed of measuring 6,000,000-15,000,000 Point/ h.
3D Laser Scanner Specification:

Scanning Samples:

Delivery Time:

7 days after we receive payment.

Warranty:

12 months dating from you receiving the equipment.

During warranty period, if some part is broken due to manufacturing defect, we will send you new one to replace by free cost and free shipment.

After-sale Service:

We will provide you free technical supporting during the whole lifespan of the equipment.

Payment Item:

1. In EXW, FOB, DDU, DDP incoterms, T/T 50% deposit in advance, the balance payment should be settled before shipment.

2. In C&F and CIF incoterms, T/T 50% deposit in advance, the balance payment should be settled within 1 week after buyer receiving the copy of B/L via e-mail or fax.

We accept payment by T/T, Western Union. If order amount is more than USD10,000, L/C at sight is acceptable.

How to contact us:
